2018 Good Quality PP Yarn Water Filter Cartridge Making Machine

Name: 2018 Good Quality PP Yarn Water Filter Cartridge Making Machine
Brand: AJMS
Price: 2300 USD

China 2018 Good Quality PP Yarn Water Filter Cartridge Making Machine wholesale

Brand Name : AJMS

Model Number : AJMS1803

Certification : CE, ISO

Place of Origin : China

MOQ : 1 set

Price : USD2300 - USD4700 per set

Payment Terms : L/C, T/T

Supply Ability : 1000 sets per month

Delivery Time : within 1 week

Packaging Details : by plywood case

Product name : PP Yarn Water Filter Cartridge Making Machine

Size : 10"&20"

Power : 430W

Output : 95-110pcs/H

Winding line speed : 40-280m/min

Power supply : three-phase 220V/50HZ, one-phase 380V/50HZ

Motor power : 180W/spindle, 250W/spindle

Motor speed : 2800r/min

Winding frame material : polypropylene, stainless steel etc,.

Single spindle panel size : (WxH) 390x308mm

Contact Now

2018 Good Quality PP Yarn Water Filter Cartridge Making Machine

PP string wound filter cartridge making machine is professionally produce all kinds of pp string wound filter cartridge with different micros and patterns.

PP String wound cartridges offer true depth filtration with high dirt holding capacity and extremely low media migration. It is manufactured using a high speed, continuous wind process which creates a superior one-piece filter with hundreds of diamond shaped tunnels that get progressively smaller from the outer diameter to the core. Finer particles are progressively trapped as fluid travels to the center of the filter allowing for much greater retention capacity than that which is associated with straight surface filter media of the same dimensions and porosity

All types of Machine

1.Single Head:

10’’ single head

20’’ single head

30’’ single head

40’’ single head

5’’,50’’,60’’,70’’,80’’...

100’’

2.Double Head:

10’’&10’’ double head

10’’&20’’ double head

30’’&40’’ double head

20’’&30’’ double head

40’’&40’’,10’’&30’’,

20’’ & 40’’....

Specifications of machines

Specification
1	type		power	Output(piece/hour)			mark
2	10inch		180W	50-60
3	20inch		250W	45-55
4	30inch		370W	25-30
5	40inch		370W	20-25
6	10inch&10inch		360W	100-120
7	10inch&20inch		430W	95-115
10&20 machine dimension :(LWH) :12006001250mm
30&40 machine dimension :(LWH) :18006001250mm

After packing size
Machine type		After packing size(LWH mm)			Net weight (KG)	Gross weight (KG)
Single
10inch		10506501400			50	80
20inch		12006001400			80	100
30inch		15006501400			100	120
50inch		21506501400			220	260
60inch		23006501400			220	300
70inch		26006501400			150	180
Double
10&10 inch		10506501400			80	100
10&20 inch		12006501400			110	150
20&30 inch		15006501400			180	200
30&40 inch		18506501400			220	260
40&40 inch		18006501250			250	280

Payment & Delivery

Payment: T/T, 30% in advance and balance before shipment

Delivery time: 8-10 working days upon date of receipting deposit

Min order: 1 set

Guarantee time: 1 year

Default Voltage:3-Phase 380V/50HZ or 60HZ,1-Phase 220V/50HZ.if your side is different from

us,we could change as your side.

Package: wooden case

2018 Good Quality PP Yarn Water Filter Cartridge Making Machine

Finished products

2018 Good Quality PP Yarn Water Filter Cartridge Making Machine

2018 Good Quality PP Yarn Water Filter Cartridge Making Machine Images
